How are the BOOT_SEL0# and BOOT_SEL1# pins configured on the G47M module to manage boot selection and UART debugging functionality?

For BOOT_SEL0#, an 1K Ohm series termination resistor is provided in (OSM Pin) CPU, initially the boot selection status will be read, and later CPU will start to transmit data through debug UART (UART_CON_TX) and it is recommended to use 220E series resistor with GND pin while using a 2.54mm Jumper.

For BOOT_SEL1#, should go low only during flashing time and while booting its status will be high so it won’t affect the UART function.
